DC Fuse For Energy Storage System

Widely used in battery modules, battery clusters/battery packs, AC/DC converter inverters, and other circuits; effectively protect the electrical equipment in energy storage systems from damage caused by overcurrent, short circuits, etc.

SLES-00L61

Technical Parameters：
Reference Standard：GB/T 13539.4、IEC60269-4、UL248-13
Rated Voltage：DC 400V
Rated Current：63A~500A
Interruting Capacity：50kA
Class of Operation：aR
Safety Certificate：UL
※ Please refer to the model specification for details！

SLES-00P50

Technical Parameters：
Reference Standard：GB/T 13539.4、IEC60269-4、UL248-13
Rated Voltage：DC 500V；
Rated Current：63A-500A；
Interruting Capacity：50kA；
Class of Operation：aR
※ Please refer to the model specification for details!

SLES-00P51

Technical Parameters：
Reference Standard：GB/T 13539.4、IEC60269-4、UL248-13
Rated Voltage：DC 500V；
Rated Current：63A-500A；
Interruting Capacity：50kA；
Class of Operation：aR
Safety Certificate：UL
※ Please refer to the model specification for details!

SLES705-2E

Technical Parameters：
Reference Standard：GB/T 13539.4、IEC60269-4、UL248-13
Rated Voltage：DC 1500V
Rated Current：100A~630A
Interruting Capacity：250kA
Class of Operation：aR
Safety Certificate：UL
※ Please refer to the model specification for details!

SLES705-3E

Technical Parameters：
Reference Standard：GB/T 13539.4、IEC60269-4、UL248-13
Rated Voltage：DC 1500V
Rated Current：200A~900A
Interruting Capacity：250kA
Class of Operation：aR
※ Please refer to the model specification for details!

SLES705-5P

Technical Parameters：
Reference Standard：GB/T 13539.4、IEC60269-4、UL248-13
Rated Voltage：DC 1500V
Rated Current：450A~2000A
Interruting Capacity：250kA
Class of Operation：aR
※ Please refer to the model specification for details！

SLES705-7P

Technical Parameters：
Reference Standard：GB/T 13539.4、IEC60269-4、UL248-13
Rated Voltage：DC 1500V
Rated Current：1250A~3000A
Interruting Capacity：250kA
Class of Operation：aR
Safety Certificate：TUV
※ Please refer to the model specification for details！
